The programmer is connected to the USB port via USB Type A to Mini B cable, which is also included in the kit.įor the full operation of the programmer download the driver from the Pololu official website. The programmer is connected to the target device using the supplied 6-pin ISP cable. The programmer emulates STK500 through a virtual serial port, which makes it compatible with standard software such as Atmel studio and AVR DUDE. Pololu USB is a compact and inexpensive in-circuit programmer for AVR-based controllers. In order to connect the microcontroller to the computer we will use the Pololu USB AVR Programmer. You can download the free full version of Atmel studio 7 from the official Microchip Technology website.
To upgrade the firmware of the Atmega 8 microcontroller we will use the Atmel studio 7. Let’s proceed to the software part of the spectrum analyzer.
Inside the box the printed circuit boards are neatly folded in a vacuum packing. The printed circuit boards are delivered in a box with the name of the manufacturer.
You can also use specific Gerber files from the archive and upload them manually.ĥ.Afterwards place an order at the designated address and select the preferred delivery time. 1.In order to start assembling the LED spectrum analyzer, you need to find out more about the control circuit diagram and the circuit diagram of the LED matrix by registering on the EasyEDA website or by downloading the archive following the link in step 2.Ģ.On the EasyEDA website we create Gerber files from the converted printed circuit boards of spectrum analyzer for further production at the factory.ģ.Before going to the official website of the printed circuit board manufacturer, the EasyEDA development environment shows us brief information about the characteristics of the printed circuit boards and an approximate cost for 10 pieces.Ĥ.On the website of the printed circuit board manufacturer JLCPCB files can be downloaded automatically through the EasyEDA Gerber development environment.
